Fuel level measurement systems
Never measure with gauge rods again!
We will provide you with a complete overview of your fuel inventory and its quality. You will always have all the information at your fingertips, anytime and anywhere.
Interested in more details? Check out the article about fuel level measurement on our blog.
přehled zařízení/systémů
MONTI Extra
The highest possible accuracy in fuel measurement on the global market. We guarantee a maximum deviation of 0,1 mm.
The choice for those who want the best.
- Continuous bidirectional monitoring of tank depletion and fuel dispensers flow
- Suitable for all types of fuels
- Monitoring fuel quality
- Measures the amount of water and other contaminants
- Installation during the operation of the fuel tank – the petrol station remains operational
MP X
Diemsions (W×H×D): 44 x 33 mm, up to approx. 3150 mm
Power supply: 9 - 16 VDC, 30 mA
Power consumption: 400 mW
Protection rating: IP68
Protection class: II 1G (EEx) ia IIB T4
Operating temperature: -20° to +40°
Temperature measurement range: -20° to +80°
Measuring length: 0 to 2870 mm
Number of temperature sensors: max. 8
Measurement accuracy: 0,1 mm
MONTI Easy
Precise measurement of fuel with a deviation of 1 mm.
A compromise for those who prefer a balanced solution.
- Best suited for determining the current tank inventory
- Automatic detection of fuel delivery
- Installation during the operation of the fuel tank – the petrol station remains operational
MP E
Dimensions (W×H×D): 44 x 33 mm, up to approx. 3150 mm
Power supply: 9 - 16 VDC, 30 mA
Power consumption: 400 mW
Protection rating: IP68
Protection class: II 1G (EEx) ia IIB T4
Operating temperature: -20° to +40°
Temperature measurement range: -20° to +80°
Measuring length: 0 to 2870 mm
Number of temperature sensors: max. 8
Measurement accuracy: 1 mm
MONTI AdB
As environmental limits increase, a rise in AdBlue consumption can be expected. With us, you will be prepared and have an overview of the AdBlue levels at your petrol station.
- Enables an unattended solution with remote display
- Simple and economical product
- Operational durability and long lifespan
- Minimal maintenance requirements
MP AdB
Dimensions (W×H×D): 27 × 100 mm
Power supply: 24 VDC +- 2,4 V
Power consumption: –
Input fuse: 10 A
Protection rating: IP68
Protection class: Exiall CT6 Ga
Operating temperature: -20° to +60°
Temperature measurement range: -20° to +60 °
Measuring length: 0 to 3 m
Number of temperature sensors: 1
Measurement accuracy: 0,25% of the measured range per year
MONTI Pascal
The least expensive, yet still high-quality solution.
- Traditional measurement system
- High operational durability
- Good price-to-performance ratio
- Easy installation
MP P
Dimensions (W×H×D): 27 × 147 mm
Power supply: 12 - 30 VDC
Power consumption: –
Protection rating: IP68
Protection class: Exiall CT6
Operating temperature: -20° to +70°
Temperature measurement range: -20° to +70°
Measuring length: 0 to 3 m
Number of temperature sensors: 1
Measurement accuracy: 0,25% of the measured range per year
